Effortless Arc Flash Label Management

LabelQC.com makes arc flash label management easy with secure QR codes linked to up-to-date online labels. Quickly add or update equipment labels by uploading a CSV file, ensuring workplace safety and compliance without the hassle of reprinting labels.

⚠️ CAUTION ARC FLASH HAZARD

Equipment:Power Distribution Panel PDP-5

Location:Data Center A

Company:Example Inc

Incident Energy:6.3 cal/cm²

Arc Flash Boundary:34 ft

Working Distance:17 in

Shock Hazard:208 V

Can cause burns or injury

Wear Category 1 PPE

Date:04/01/2025

Comment:Server room

Simplify Arc Flash Labeling

• Create secure QR codes for always-current arc flash labels.
• Organize and manage label data in a single, accessible system.
• Easily track and audit labeled equipment.
• Stay compliant with NFPA 70 and NFPA 70E standards.

Improve Compliance

NFPA 70 (National Electrical Code) requires warning labels on equipment that may be serviced while energized. NFPA 70E (Standard for Electrical Safety in the Workplace) mandates arc flash labels with details like incident energy, PPE categories, and arc flash boundaries.

Labels must be reviewed and updated every 5 years or after significant electrical system changes, such as new equipment or modifications, to maintain compliance and ensure worker safety.

How It Works

1. Upload a CSV file with your arc flash data (we will help you!).
2. LabelQC.com generates unique QR codes for each piece of equipment.
3. Print and attach QR codes to equipment; scanning provides instant access to the latest label data online.
4. Update labels anytime by uploading a revised CSV, keeping information current without reprinting.

Smart Labels for Safety

Each QR code links to an online arc flash label with critical safety information, such as:

• Incident Energy: Measures potential burn risk (cal/cm²).
• Arc Flash Boundary: Safe distance from equipment (feet).
• PPE Level: Required protective gear (e.g., Category 2).
• Shock Hazard: Voltage level.

Scanning a QR code ensures workers always see the latest data, reducing risks from outdated labels. QR codes are ubiquitous in modern life, making them easy to use and understand.

Try It!

Explore example arc flash labels for Example Inc, including QR codes to view real-time safety information for panelboards, switchboards, switchgear cubicles, and motor control centers.

Company	Device Tag	Equipment Name	Location	QR Code	Actions
Example Inc	pdp-5	Power Distribution Panel PDP-5	Data Center A		View
Example Inc	mcc-3	Motor Control Center MCC-3	Substation B - Floor 1		View
Example Inc	pnl-1	Panelboard PNL-1	Control Room C		View
Example Inc	swb-2	Switchboard SWB-2	Switchgear Room D		View
Example Inc	swg-4	Switchgear Cubicle SWG-4	Turbine Module E		View

Get in Touch

Like what you see? Contact us for more information or to get started with LabelQC.com.
